MP260 Planer / Moulder

Starting at
£9,497.00
Out of stock

* Above price is for the MP260 (MP260EH12S) with one feed speed, 3-phase 400 V.

Other configurations vary in price.

Print Add to Compare
Compact and versatile four-sided planer / moulder

The MP260 is an ideal choice for individuals and businesses who need an efficient, versatile and precise machine.

Benefits
  • 4-sided planing and profiling in one pass.
  • Large 4-sided cutting capacity - 260 mm wide x 100 mm high.
  • Easy to adjust, handle and use on a daily basis.
Description MP260 Planer / Moulder

The four-sided MP260 is a universal and compact planer/moulder designed for professional carpenters and woodworkers from the construction and building industry. It’s an easy-to-use and affordable machine which planes or moulds four sides at the same time. It allows for the production of a variety of professionally finished materials, such as floor boards, profiled boards, decorative borders, panels, window and door frames, furniture finishing elements and more.

The MP260 features two horizontal cutterheads – the 410-mm-wide top cutterhead and the 300-mm-wide bottom cutterhead, as well as two side cutterheads, each with a maximum of 100 mm high. One of these side cutterheads is mounted on a fixed spindle, while the other one is moveable. Each side cutterhead comes standard with two HSS straight cutting knives at proper lengths. For all cutterheads, a variety of optional profile knives with different shapes and dimensions are also available. The four-sided processing operation is done in one pass which helps considerably to save time and increases the efficiency of work.

There are five feed rollers which advance the material along the cutterheads in a smooth and consistent way. Depending on needs, standard steel feed rollers can be replaced with optional hardened steel rollers for increased performance, or with optional polyurethane rollers which further protect the material surface.

The work table is made of quality cast iron, machined on modern CNC tools in order to make it as stable as possible during work. Just above the feed table, within the operator’s reach, there’s an easy-to-use control panel. The electrical motors with the total power of 12,5 kW are powerful, economical, and quiet.

The MP260 features four sawdust exhaust ports – one with the diameter of 125 mm, and the other three ports with 100 mm. All the ports are placed in the most optimal places to effectively extract the sawdust from the cutterheads, as well as to keep the workplace clean.

With the MP260 planer/moulder you can process the material up to the height of 100 mm, but in order to mould or profile the side surfaces of this high material, you need to adjust the machine and install the optional 100 mm high side cutterheads.

For installing cutterheads, you need to use special flattened nuts. The maximum moulding width of four-sided material processing (with 4 cutterheads engaged) is 260 mm. It can be increased to 300 mm by removing 2 side cutterheads and using two horizontal cutterheads (2-sided process), or even further increased to 410 mm at 1-sided moulding – when only the top cutterhead is engaged.

Read More
Videos MP260 Planer / Moulder
Features MP260 Planer / Moulder
With the LT15 Mobile, we can mill the logs right at the spot and shape our products the way we want. For example, while clearing the old orchard from unwanted trees, we can decide about the shape of our future products.
Kamil Broda, OLD Mountains company
Skarżysko-Kamienna, Poland
Read the Story
Around the World

More Success Stories

Specifications MP260 Planer / Moulder
Specifications
4-sided Moulding Capacity
Max. Width 260 mm
Max. Height 100 mm
2-sided Moulding Capacity
Max. Width 300 mm
Max. Height 230 mm
1-sided Moulding or Thicknessing Capacity
Max. Width 410 mm
Max. Height 230 mm
Features & Options
Number of Horizontal Cutters 2
Number of Spindles 2
Number of Sawdust Extraction Ports 4
Viewing Window Yes
Options Infeed / Outfeed Tables - 1.2 m each
Transport wheels
Upper Horizontal Cutter
Diameter 72 mm
Width 410 mm
Power 4 kW (5.5 HP)
Rotation Speed 6000 RPM / 50 Hz
Max. Cutting Depth 8 mm
Max. Profile Depth 20 mm
Lower Horizontal Cutter
Diameter 72 mm
Width 300 mm
Power 3 kW (4 HP)
Rotation Speed 6000 RPM / 50 Hz
Max. Cutting Depth 8 mm
Max. Profile Depth 15 mm
Vertical Cutters
Spindle Diameter 30 mm
Max. Cutter Height 100 mm
Max. Diameter 140 mm
Power 3 kW (4 HP)
Rotation Speed 6000 RPM / 50Hz
Max. Cutting Depth 30 mm
Standard Vertical Cutters Included
Type TB90
Diameter 90 mm
Height 40 mm
Knife Type HSS
Knife Width 50 mm
Power Feed
Feed Motor 0.37 kW (0.5 HP)
Feed Speed 2 - 12 m/min / 50 Hz
2.5 - 14 m/min / 60 Hz
Feed Rollers 4 Steel + 1 Polyurethane Rollers
5 Polyurethane Rollers (Optional)
Dimensions & Weight
Length 1100 mm
Width 900 mm
Height 970 mm
Weight 410 kg
Shipment Weight 495 kg
Machine Standards & Requirements
Total Power 13.4 kW (18 HP)
Electrical Requirements 3-phase, 400-440 V, 16 A
3-phase, 230 V, 20 A
1-phase, 230 V, 32-50 A
Sawdust Collection Port Diameter 3 x 100 mm + 1 x 125 mm
Safety Standards CE
